WiTech MI

– Convenient use of personal Bluetooth headsets
– Comprehensive while cost-efficient way to organize intercom
– Easy to use intuitive interface
– Quick setup
– Perfect for shooting standups, coordination of cranes, spiders and other special camera equipment
WiTech MI would help you with:
– The work of the news team
– Mobile TV shooting from vehicles.
– The work of special camera equipment.
To begin with, a total of 6 clients can be connected - 3 wireless, 2 wired and 1 external wired (Ext). All different combinations between them are possible. WiTech MI clients communicate with each other according to a preset configuration.

Moreover, it is possible to set up internal connections (number of participants, volume level etc). The 'Talk' button activates an alternative communication setup. Volume level as well as activation of client response can be accessed with the help of the respective buttons on the BT-headset given the commands are supported.

One of the wireless ports can also be set to work with a mobile phone. The maximum of 5 presets each assigned to the respective headset can be saved
To begin with, a total of 6 clients can be connected - 3 wireless, 2 wired and 1 external wired (Ext). All different combinations between them are possible. WiCO MI clients communicate with each other according to a preset configuration.

Moreover, it is possible to set up internal connections (number of participants, volume level etc). The 'Talk' button activates an alternative communication setup. Volume level as well as activation of client response can be accessed with the help of the respective buttons on the BT-headset given the commands are supported.
One of the wireless ports can also be set to work with a mobile phone. The maximum of 5 presets each assigned to the respective headset can be saved

Ways of connection

Specification

  • Wireless Technology

    Bluetooth Class 1

    Working Range

    Up to 100 meters (300 ft)*

    *Depending on headset

    Frequency Band

    2.402 GHz to 2.480 GHz

    Power Output

    50 mW

    Bluetooth profile

    HSP, HFP

    Transmit Antennas

    Internal

  • Bluetooth Ports

    Two ports Master mode

    One port Master/Slave mode

    Analog Audio Ports

    One line-level port with galvanic isolation

    Two Mic/Line level ports with phantom power and differential In/Out lines

    Connectors

    Two options are available:

    • 3x Lemo FGG/EGG 0B

    • 4x 3.5 Jacks+Micro USB

  • User Interface

    OLED display for enhanced visibility

    Temperature

    Operating -10˚C to +50˚C

    (32˚F to 122˚F)

    Power

    Power supply via USB 5-14v

    Power Consumption

    Nominally 3W

    Size & Weight

    126 (L) x 22 (H) x 80 (W)mm 120g
